Created to elevate the legendary Ninja experience, the Ninja 650 combines responsive parallel-twin performance, sharp chassis control, and advanced technology in a rider-friendly package.
Upgraded suspension and braking components enhance rider confidence, while comfortable ergonomics ensure an enjoyable ride, from daily commutes to weekend escapes.
Ninja 650
Metallic Flat Spark Black / Metallic Carbon Gray
Specifications
Engine
Engine type | Liquid-cooled, 4-stroke, parallel twin |
Compression ratio | 10.8:1 |
Valve system | DOHC, 8 valves |
Bore x stroke | 83.0 x 60.0 mm |
Displacement | 649 cm³ |
Fuel system | Fuel injection with dual throttles: 36 mm x 2 |
Lubrication | Forced lubrication, semi‑dry sump |
Starting system | Electric |
Ignition system | Digital |
Performance & Transmission
Maximum power | 50.2 kW {68 PS} / 8,000 rpm |
Maximum torque | 64.0 N•m {6.5 kgf•m} / 6,700 rpm |
CO2 emission | 107.0 g/km |
Fuel consumption | 4.4 l/100km |
Fuel consumption 35 kW kit | 4.5 l/100km |
Transmission | 6-speed, return shift |
Clutch | Wet, multi disc |
Primary reduction ratio | 2.095 (88/42) |
Gear ratios 1st | 2.438 (39/16) |
Gear ratios 2nd | 1.714 (36/21) |
Gear ratios 3rd | 1.333 (32/24) |
Gear ratios 4th | 1.111 (30/27) |
Gear ratios 5th | 0.966 (28/29) |
Gear ratios 6th | 0.852 (23/27) |
Final drive | Chain |
Final reduction ratio | 3.067 (46/15) |
Frame & Dimensions
Frame type | Trellis, high-tensile steel |
Rake | 24.0 ° |
Trail | 100 mm |
Wheel travel front | 125 mm |
Wheel travel rear | 130 mm |
Tyre, front | 120/70 ZR17 M/C (58W) |
Tyre, rear | 160/60 ZR17 M/C (69W) |
L x W x H | 2,045 x 740 x 1,140 mm |
Steering angle L/R | 32° / 32° |
Wheel base | 1,395 mm |
Ground clearance | 125 mm |
Fuel capacity | 15.0 litres |
Seat height | 785 mm |
Curb mass* | 194 kg |
| *Curb mass includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). |
Estimated dry weight** | 179 kg |
| **Estimated Dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). |
Brakes & Suspension
Front brake type | Dual semi-floating discs |
Front brake diameter | Ø 300 mm |
Front brake caliper type | Radial-mount, opposed 4-piston |
Rear brake type | Single disc |
Rear brake diameter | Ø 220 mm |
Rear brake caliper type | Single-piston |
Front suspension type | Inverted Separate Function fork (SFF-BP) |
Front suspension diameter | Ø 37 mm |
Rear suspension type | Horizontal Back-link with spring preload adjustability |
