Engine type

Air-cooled, 4-stroke, V-twin

Compression ratio

8.4:1

Valve system

SOHC, 4 valves

Bore x stroke

77.0 x 83.0 mm

Displacement

773 cm³

Fuel system

Fuel injection: 34 mm x 2

Lubrication

Forced lubrication, wet sump

Starting system

Electric

Ignition system

Digital

Maximum power

35.0 kW {48 PS} / 6,000 rpm

Maximum torque

62.9 N•m {6.4 kgf•m} / 4,800 rpm

CO2 emission

119 g/km

Fuel consumption

4.8 l/100km

Transmission

5-speed, return shift

Clutch

Wet, multi disc

Primary reduction ratio

2.095 (88/42)

Gear ratios 1st

2.353 (40/17)

Gear ratios 2nd

1.591 (35/22)

Gear ratios 3rd

1.240 (31/25)

Gear ratios 4th

1.000 (28/28)

Gear ratios 5th

0.852 (23/27)

Final drive

Sealed chain

Final reduction ratio

2.467 (37/15)

Frame type

Double-cradle, high-tensile steel

Trail

108 mm

Wheel travel front

130 mm

Wheel travel rear

107 mm

Tyre, front

100/90-19 M/C 57H

Tyre, rear

130/80-18 M/C 66H

L x W x H

2,190 x 790 x 1,075 mm

Steering angle L R

37° / 37°

Wheel base

1,465 mm

Ground clearance

125 mm

Fuel capacity

15.0 litres

Seat height

790 mm

Curb mass

226 kg

Front brake type

Single disc

Front brake diameter

Ø 320 mm

Front brake caliper type

Dual-piston

Rear brake type

Single disc

Rear brake diameter

Ø 270 mm

Rear brake caliper type

Dual-piston

Front suspension type

Telescopic fork

Front suspension diameter

Ø 41 mm

Rear suspension type

Twin shocks with spring preload adjustability
