Engine type

Liquid-cooled, 4-stroke, in-line four

Compression ratio

12.9:1

Valve system

DOHC, 16 valves

Bore x stroke

67.0 x 45.1 mm

Displacement

636 cm³

Fuel system

Fuel injection with oval sub-throttles: 38 mm x 4

Lubrication

Forced lubrication, wet sump with oil cooler

Starting system

Electric

Ignition system

Digital

Maximum power

91.0 kW {124 PS} / 13,000 rpm

Maximum power with RAM Air

95.2 kW {129 PS} / 13,000 rpm

Maximum torque

69.0 N•m {7.0 kgf•m} / 10,800 rpm

CO2 emission

145 g/km

Fuel consumption

6.1 l/100km

CO2 emission 85 kW kit

147 g/km

Fuel consumption 85 kW kit

6.2 l/100km

Transmission

6-speed, return shift

Primary reduction ratio

1.900 (76/40)

Gear ratios 1st

2.846 (37/13)

Gear ratios 2nd

2.200 (33/15)

Gear ratios 3rd

1.850 (37/20)

Gear ratios 4th

1.600 (32/20)

Gear ratios 5th

1.421 (27/19)

Gear ratios 6th

1.300 (26/20)

Final drive

Sealed chain

Final reduction ratio

2.867 (43/15)

Frame type

Perimeter, aluminium

Trail

101 mm

Wheel travel front

120 mm

Wheel travel rear

151 mm

Tyre, front

120/70 ZR17 M/C (58W)

Tyre, rear

180/55 ZR17 M/C (73W)

L x W x H

2,025 x 710 x 1,105 mm

Steering angle L R

27° / 27°

Wheel base

1,400 mm

Ground clearance

130 mm

Fuel capacity

17.0 litres

Seat height

830 mm

Curb mass

198 kg

Front brake type

Dual semi-floating discs

Front brake diameter

Ø 310 mm

Front brake caliper type

Radial-mount, monobloc, opposed 4-piston

Rear brake type

Single disc

Rear brake diameter

Ø 220 mm

Rear brake caliper type

Single-bore pin-slide

Front suspension type

Inverted Separate Function fork (SFF-BP) with compression and rebound damping, spring preload adjustability, and top-out springs

Front suspension diameter

Ø 41 mm

Rear suspension type

Bottom-link Uni-Trak, gas-charged shock with piggyback reservoir, compression and rebound damping, and spring preload adjustability
