The Ninja 1100SX offers the ultimate in sport touring ability. Created to deliver high performance, advanced technology, and superb comfort for sports riding and all-day touring, the Ninja 1100SX sets a new standard for sport touring performance.
The Ninja 1100SX offers the ultimate in sport touring ability. Created to deliver high performance, advanced technology, and superb comfort for sports riding and all-day touring, the Ninja 1100SX sets a new standard for sport touring performance.
Engine type | Liquid-cooled, 4-stroke, in-line four |
Compression ratio | 11.8:1 |
Valve system | DOHC, 16 valves |
Bore x stroke | 77.0 x 59.0 mm |
Displacement | 1,099 cm³ |
Fuel system | Fuel injection: 38 mm x 4 |
Lubrication | Forced lubrication, wet sump |
Starting system | Electric |
Ignition system | Digital |
Maximum power | 100.0 kW {136 PS} / 9,000 rpm |
Maximum torque | 113.0 N•m {11.5 kgf•m} / 7,600 rpm |
CO2 emission | 126 g/km |
Fuel consumption | 5.6 l/100km |
CO2 emission 85 kW kit | 126.0 g/km |
Fuel consumption 85 kW kit | 5.6 l/100km |
Transmission | 6-speed, return shift |
Clutch | Wet, multi disc |
Primary reduction ratio | 1.528 (81/53) |
Gear ratios 1st | 2.600 (39/15) |
Gear ratios 2nd | 1.950 (39/20) |
Gear ratios 3rd | 1.600 (24/15) |
Gear ratios 4th | 1.389 (25/18) |
Gear ratios 5th | 1.217 (28/23) |
Gear ratios 6th | 1.069 (31/29) |
Final drive | Sealed chain |
Final reduction ratio | 2.800 (42/15) |
Frame type | Twin-tube aluminium |
Trail | 98 mm |
Wheel travel front | 120 mm |
Wheel travel rear | 141 mm |
Tyre, front | 120/70 ZR17 M/C (58W) |
Tyre, rear | 190/50 ZR17 M/C (73W) |
L x W x H | 2,100 x 805 x 1,190 mm (1225 mm high position screen) |
Steering angle L/R | 31° / 31° |
Wheel base | 1,440 mm |
Ground clearance | 135 mm |
Fuel capacity | 19.0 litres |
Seat height | 835 mm |
Curb mass* | 234 kg |
| *Curb mass includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). |
Estimated dry weight** | 213 kg |
| **Estimated Dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). |
Front brake type | Dual semi-floating discs |
Front brake diameter | Ø 300 mm |
Front brake caliper type | Brembo radial-mount, M4.32 monobloc, opposed 4-piston |
Rear brake type | Single disc |
Rear brake diameter | Ø 260 mm |
Rear brake caliper type | Single-piston |
Front suspension type | Inverted fork with compression and rebound damping, and spring preload adjustability |
Front suspension diameter | Ø 41 mm |
Rear suspension type | Horizontal Back-link, Öhlins S46 gas-charged rear shock with rebound damping adjustability and remote spring preload adjustability |
