Tackle tough trails and tasks with the new Brute Force 750 ATV. This versatile model features rugged capability and unrivaled all-day comfort to finish the job and get you where you need to go. With responsive power, sporty handling, and Kawasaki build quality, you can take on more with confidence.
Engine type | Liquid-cooled, 4-stroke, V-twin |
Compression ratio | 9.3:1 |
Valve system | SOHC, 8 valves |
Bore x stroke | 85.0 x 66.0 mm |
Displacement | 749 cm³ |
Fuel system | Fuel injection: 34 mm x 2 |
Lubrication | Forced lubrication, wet sump |
Starting system | Electric |
Ignition system | Digital DC-CDI |
Maximum power | 37.3 kW {51 PS} / 6,750 rpm |
Maximum torque | 58.1 N•m {5.9 kgf•m} / 4,750 rpm |
Transmission | 2-speed & reverse, automatic |
Primary drive | Belt drive torque converter (CVT) |
Final drive | Shaft 2WD/4WD |
Frame type | Tubular double-cradle, high-tensile steel |
Trail | 10 mm |
Wheel travel front | 175 mm |
Wheel travel rear | 189 mm |
Tyre, front | AT 25 x 8-12 |
Tyre, rear | AT 25 x 10-12 |
L x W x H | 2,185 x 1,170 x 1,210 mm |
Steering angle L/R | 47° / 47° |
Wheel base | 1,285 mm |
Ground clearance | 228 mm |
Fuel capacity | 19.0 litres |
Seat height | 895 mm |
Curb mass | 333 kg |
Parking brake | Enclosed wet multi-plate |
Front brake type | Dual discs |
Front brake diameter | Ø 200 mm |
Front brake caliper type | Dual-piston |
Rear brake type | Enclosed wet multi-plate |
Front suspension type | Double wishbone with 5-way spring preload adjustability |
Rear suspension type | Double wishbone with 5-way spring preload adjustability |
